Type
The capacity
Function
MULTI DUAL TIMER
Rating Voltage
220VAC, 12VDC, 24VDC, 110VDC
Voltage variable range
AC : 90% ~ 110%
DC : 93% ~ 110%
Contact form
¼ø½Ã
-
ÇѽÃ
ON(A) : 1a, ON(B) : 1a
The range of frequency
50/60Hz
Contact capacity
3A, 250VAC
Repetition error
¡¾0.04%
Temperature error
¡¾0.025%
Voltage error
¡¾0.02%
SET error
¡¾0.02%
Range of used temperature
-10¡É ~ +50¡É
Withstand voltage
AC 2000V, 1minute(Between charging metal part and non-charging metal part)
The anti-noise
(Burst Generator Pulse range 10§Á) 2kv
Insulation resistance
Over 100M¥Ø(DC500V insulate resistance meter)
Ambient humidity
40~85% RH
Power consumption
0.95VA
Applicable socket
Exposed type : DT-08 / Retreated type : DTY-03
Form
S/W
ON TIME
Maximum time
OFF TIME
Maximum time
SM4-A
1 Step
0.02 sec ~ 30 sec
30 SEC
0.02 sec ~ 10 sec
10 SEC
2 Step
0.02 sec ~ 300 sec
300 SEC
0.02 sec ~ 100 sec
100 SEC
SM4-B
1 Step
0.02 sec ~ 60 sec
60 SEC
0.02 sec ~ 10 sec
10 SEC
2 Step
0.02 sec ~ 600 sec
600 SEC
0.02 sec ~ 100 sec
100 SEC
