Type The capacity
Function SINGLE TIMER
Rating Voltage

110VAC / 220VAC
12VDC, 24VDC, 110VDC

Voltage variable range AC : 90% ~ 110%
DC : 93% ~ 110%
Contact form ¼ø½Ã 1a
Çѽà 1a1b
The range of frequency 50/60Hz
Contact capacity 3A, 250VAC
Repetition error ¡¾0.04%
Temperature error ¡¾0.025%
Voltage error ¡¾0.02%
SET error ¡¾0.02%
range of used temperature -10¡É ~ +50¡É
Withstand voltage AC 2000V, 1minute(Between charging metal part and non-charging metal part)
The anti-noise (Burst Generator Pulse range 10§Á) 2kv
Insulation resistance Over 100M¥Ø(DC500V insulate resistance meter)
Ambient humidity 40~85% RH
Power consumption 0.9VA
Applicable socket Exposed type : DT-08 / Retreated type : DTY-03

Maximum time Range of control time Maximum time Range of control time
1 SEC 0.02 sec ~ 1 sec 6 MIN 0.02 sec ~ 6 min
3 SEC 0.02 sec ~ 3 sec 12 MIN 0.02 sec ~ 12 min
6 SEC 0.02 sec ~ 6 sec 30 MIN 0.02 sec ~ 30 min
12 SEC 0.02 sec ~ 12 sec 60 MIN 0.02 sec ~ 60 min
30 SEC 0.02 sec ~ 30 sec 3 HOR 0.02 sec ~ 3 hor
60 SEC 0.02 sec ~ 60 sec 10 HOR 0.02 sec ~ 10 hor
3 MIN 0.02 sec ~ 3 min 30 HOR 0.02 sec ~ 30 hor
