| Type |
DSF-202W (For Water) |
DSF-202O (For Oil) |
| Usage |
Well water, City water, Sea water |
Crude oil, Light oil, Lamp oil |
| Specific Gravity |
0.85~1.05 |
0.7~0.9 |
| Applicable surrounding temperature |
0~50กษ |
0~70กษ |
| Output contact |
1c. AC250V 10A Resistance load
1c. AC250V 5A Conduction load
1c. AC250V 1.5A Motor load |
| Range of control |
20Cm ~ 10m |
| Pressure in water tank |
1 Air pressure |
|
| |
 |
| |
 |
| |
 |
| |
 |
|
