| Type |
DSB-365(¥Õ65) |
DSB-365D(¥Õ65) |
DSB-386 |
DSB-386D |
| Power |
110VAC (50/60Hz) |
12VDC |
110VAC (50/60Hz) |
12VDC |
| 220VAC (50/60Hz) |
24VDC |
220VAC (50/60Hz) |
24VDC |
| A tone |
Alarm Sound |
MELODY
(home sweet home) |
Alarm Sound |
MELODY
(home sweet home) |
| Volume of Sound |
90 dB |
85 dB |
90 dB |
85 dB |
| Range of used temperature |
-10¡É ~ +50¡É |
-10¡É ~ +50¡É |
| Ambient humidity |
40~85% RH |
40~85% RH |
| Power consumption |
5 W |
65 mA |
5 W |
65 mA |
| Attachment method |
Retreated type |
Exposed type |
¡Ø DC 110V Order made
|
| |
 |
| |
 |
|
