| Type |
DSB-325(¥Õ25) |
DSB-325D(¥Õ25) |
DSB-330(¥Õ30) |
DSB-330D(¥Õ30) |
| Power |
110VAC (50/60Hz) |
12VDC |
110VAC (50/60Hz) |
12VDC |
| 220VAC (50/60Hz) |
24VDC |
220VAC (50/60Hz) |
24VDC |
| A tone |
Alarm Sound |
MELODY
(for elise) |
Alarm Sound |
MELODY
(for elise) |
| Volume of Sound |
85 dB |
75 dB |
85 dB |
75 dB |
| Range of used temperature |
-10¡É ~ +50¡É |
-10¡É ~ +50¡É |
| Ambient humidity |
40~85% RH |
40~85% RH |
| Power consumption |
Within 3W |
About 35mA |
Within 3W |
About 35mA |
| Attachment method |
Retreated type |
Retreated type |
|
| |
 |
| |
 |
|
